High-efficacy road light with 160 lm/W across the full wattage range. Pole mount with 5 beam distribution options and optional 20KV surge protection. Ideal for collector roads and residential streets.
| Parameter | Value |
|---|---|
| CRI | ＞70 (Default), ＞80 |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Smart Control | 0-10V / DALI / D4i |
| Color Temperature | 3000K / 4000K / 5000K |
| Wattage | 35/50/70/100/120/150W |
| Efficacy | 160 lm/W |
| Lumens | Up to 24,000 lm |
| Beam Angle | Type II / III / IV / V |
| Surge Protection | 10KV (Optional 20KV) |
| Mounting | Pole |
| Input Voltage | 120-277V |
| Dimension | 632×521×228mm (24.88"×20.51"×8.98") |
| Weight | 10 kg / 22.05 lb |
| Operating Temp | -40℃ ~ 50℃ |
| Warranty | 5 Years |
| Lifetime | L90B10: 100,000 hrs @ 25℃ |
Collector Roads · Residential Streets · Parking Lots · Commercial Areas
