Slim Linear LED Tunnel Light

No.SD807

SD807 is a slim linear LED tunnel light (25W) with 135 lm/W, 3,375 lm. IP65/IK08 rated, 0-10V dimming, 110° beam, 100-277V input. Gray aluminum, 1-meter length, top or wall mounting. 5-year warranty, 50,000-hour lifetime.

Download

View all downloads

SD807 — Slim Linear LED Tunnel Light

Ultra-slim 1-meter linear tunnel light at only 25W. 110° beam for uniform illumination in narrow tunnels and corridors. Gray finish for reduced visual impact in architectural applications.

Key Features

Ultra-Slim Profile — 133mm width, minimal visual impact
25W Low Power — Energy-efficient for long tunnel runs
110° Beam — Uniform wall-to-wall coverage
1-Meter Length — Continuous run installation
Gray Finish — Blends with concrete tunnel surfaces
100-277V — Wide input voltage range

Specifications

Parameter	Value
CRI	＞70
IP Rating	IP65
IK Rating	IK08
Dimming	0-10V
Wattage	25W
Efficacy	135 lm/W
Lumens	3,375 lm
Color Temperature	3000K / 4000K / 5000K
Colors	Gray
Material	Aluminum
Beam Angle	110°
Input Voltage	100-277V
Dimension	1000×133×151mm (39.37"×5.24"×5.94")
Weight	4 kg / 8.82 lb
Operating Temp	-40℃ ~ 50℃
Warranty	5 Years
Lifetime	L70B50: 50,000 hrs @ 25℃
