Modular LED Tunnel Light with Multi-Beam

No.SD812

SD812 is a modular LED tunnel light (60-300W) with 130 lm/W efficacy. IP66/IK08 rated, 0-10V dimming, 4 beam options (30°/60°/90°/90×120°), 100-277V input. Up to 39,000 lm. Modular width scales with power. Top or wall mounting, 5-year warranty, 50,000-hour lifetime.

Download

View all downloads

SD812 — Modular LED Tunnel Light with Multi-Beam

Modular tunnel light with 4 beam distribution options. Width scales with wattage (77mm per module) for a clean, proportional appearance. Up to 39,000 lm for medium-to-large tunnel projects.

Wattage	Lumens	Dimension	Weight
60W	7,800 lm	335×77×215mm	2 kg
120W	15,600 lm	335×154×215mm	3.1 kg
180W	23,400 lm	335×231×215mm	4 kg
240W	31,200 lm	335×308×215mm	4.9 kg
300W	39,000 lm	335×385×215mm	6.1 kg

Key Features

4 Beam Options — 30°/60°/90°/90×120° for various tunnel types
Modular Width — Scales 77mm per module, proportional design
IP66 — High-pressure water jet protection
130 lm/W — Consistent efficacy across all modules
Lightweight — 2 kg for 60W, easy single-person install
Same Length — All models 335mm long, width scales only

Specifications

Parameter	Value
CRI	＞70
IP Rating	IP66
IK Rating	IK08
Dimming	0-10V
Color Temperature	3000K / 4000K / 5000K
Colors	Black
Beam Angle	30° / 60° / 90° / 90×120°
Input Voltage	100-277V
Operating Temp	-40℃ ~ 45℃
Warranty	5 Years
Lifetime	L70B50: 50,000 hrs @ 25℃
